Battery cells of Top Brands
LG M52VT 21700 5200mAh 3C Battery
LG M52VT 21700 5200mAh 3C Battery
Regular price
$2.25 USD
Regular price
$3.50 USD
Sale price
$2.25 USD
Unit price
/
per
Couldn't load pickup availability
Share
LG M52VT 21700 5200mAh 3C Battery
- >100K in stock, fresh LG INR21700M52VT Li-ion cells.
- Fast shipping by air or sea from China.
- We hold full Spec, MSDS UN38.3 SGS CB BIS UL IEC62133 UL1642 and Test reports.
Datasheet
|
Item
|
Condition / Note
|
Specification
|
|
1 Energy
|
By Std. Charge / Discharge
|
Min 18.34Wh
|
|
2 Nominal Voltage
|
Average by Std. Charge / Discharge
|
3.69V
|
|
3 Nominal Shipping
|
SOC
|
Below 30%
|
|
4 Standard Charge
|
Constant current Constant voltage
End current(Cut off) |
0.3C (1500mA)
4.2V 100mA |
|
5 Max. Charge Voltage
|
In all measurements and operations of the cell, the minimum closed circuit voltage allowable shall not be over the following
value |
4.20V 4.10V (refer to 4.2.4) |
|
6 Over Voltage Protection
|
Cell voltage should not go over the following value to prevent any safety events. And cell performance can’t be
guaranteed between 4.20V and 4.25V |
4.25V
|
|
7 Min. Discharge Voltage
|
In all measurements and operations of the cell, the minimum closed circuit voltage allowable shall not be below the following
value |
2.50 V
2.85V(refer to 4.2.4)
|
|
8 Under Voltage Protection
|
Cell voltage should not go down the following value to prevent any safety events. And cell performance can’t be
guaranteed between 2.50V and 2.00V |
2.00V
|
|
9 Standard Discharge (Refer to 4.1.2)
|
Constant current End voltage(Cut off)
|
0.2C (970mA)
2.50V |
|
10 Storage Temperature (for shipping state)
|
1 month
3 months 1 year Recovery energy** after the storage: ≥ 80% of minimum energy
|
-20 ~ 55℃
-20 ~ 45℃ -20 ~ 25℃ |
|
11 Weight
|
Without washer
|
67.4 ± 1.0 g
|
LG M52VT Max. Continual Discharge Current
-20 ~ 10℃: 0.5C (2,500mA)
10 ~ 25℃: 3.0C(15,000mA)
25 ~ 55℃: 1.5C(7,500mA)
LG M52VT Chemistry: Lithium Nickel Manganese Aluminum Cobalt Oxide
Standard: ANSI/CAN/UL/ULC 2580:2022
Use Temperature Range (°C): Environmental 0 to 45 for charge,-30 to 55 for discharge / Surface limitation 55 for charge, 70 for discharge.0 to 45 for charge, -20 to 55 for discharge (The Max. cell surface temperature should be below 50°C for charging and 70°C for discharging)
